5 | 1 customer reviews

TREK 2024 Rail 9.5 Gen 4

£3,949.99  £6,024.99
30 days free insurance available

Finance available from £74.04 per month with V12 Finance

S
M
L
XL
Available from Supplier Warehouse ( 7-10 days )
Part Number:

5303032

GTIN/UPC:

601479125807

The Rail 9.5 is a carbon electric mountain bike with long-travel suspension. It features an upgraded frame with longer reach for serious stability on the trail, and a suspension set-up and parts worthy of the gnarliest enduro laps. The powerful Bosch smart system motor will get you back up the mountain faster than you ever thought possible, and the huge 750 Wh battery makes the laps feel endless.

You're looking for a long-travel e-MTB that gives you a serious power boost without holding you back from hitting the techy terrain and big drops you love. You want to spend your cash on a carbon frame and worry about upgrading components later.

An OCLV Mountain Carbon frame with a 750 Wh Removable Integrated Battery, a super-responsive 160 mm RockShox 35 Gold RL fork with DebonAir spring, Motion Control damper and lockouts, a 150 mm RockShox Deluxe+ Select shock, the latest from Bosch with smart system Performance Line CX capable of speeds up to 20 mph (25 km/h in Europe), including a Bluetooth® LED remote for easy connectivity and activity tracking through the eBike Flow app. A Shimano Deore 12-speed drivetrain with an extra-low 52-tooth climbing gear.

The Rail 9.5 is the go-to if you want a carbon ride, and are happy to upgrade the part as you go. It keeps the price down with a Shimano Deore drivetrain, but upgrades things that matter most, like a frame with longer reach and extra stability. If you're looking for an e-MTB built to rip and upgrade over time, look no further.
- The Carbon Rail Gen 4 has the same enduro-inspired geometry and huge battery as the previous generation, but now it has a pocket in the top tube that makes Gen 4 compatible with Bosch's integrated System Controller and Mini Remote
- Trek's Removable Integrated Battery (RIB) system looks great and is super user-friendly: it fully hides the battery in the frame for protection, makes it easy to remove the battery without tools and lets you mount a water bottle cage
- Bosch's smart system gives you all the same power and responsiveness with a Bluetooth-connected LED remote and eBike Flow app that puts even more control and customisation at your fingertips
- The controller has Walk Assist and an intelligent e-MTB mode that automatically delivers the right amount of power based on your terrain
- The frame is extra-stout with a 34.9 mm seat tube to accommodate more robust dropper posts, and an oversized head tube that works with burly e-MTB optimised forks for less flex and more precise steering

Bosch Performance Line CX motor
The Bosch Performance Line CX sets the standard for eMTB performance with up to 85 Nm of torque and an intelligent eMTB mode with Extended Boost that automatically adjusts the amount of assist based on the terrain.

Removable Integrated Battery
RIB is a one-piece battery and cover with a built-in handle that can easily be removed and re-installed in the frame with no tools and no hassle. It's the most convenient way to remove your battery for transport, security or just easier charging.



Bosch Performance Line CX motor
The Bosch Performance Line CX sets the standard for eMTB performance with up to 85 Nm of torque and an intelligent eMTB mode with Extended Boost that automatically adjusts the amount of assist based on the terrain.

Bosch LED Remote
The Bosch smart system LED remote lets you easily change assist modes, activate walk mode or turn on optional lights. The bright LEDs are easy to see in any light, and show you your battery level and assist mode at a glance.



Bosch Smart System
The Bosch smart system gives you an eMTB that's more connected than ever. The LED remote connects with Bosch eBike Flow app so you can get ride stats, adjust settings and perform system updates. Plus, Bluetooth connectivity makes it easy to add a display if you want to make it easier to see your ride data.

Active Braking Pivot
Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.

Frame Size S, UNI, Carbon, OCLV Mountain Carbon main frame, 1.8'' lower head tube, Bosch System Controller-compatible, Removable Integrated Battery (RIB), Knock Block 2.0, guided internal routing, 34.9 mm seat tube, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru-axle, 150 mm travel
Wheel Size Front 29
Wheel Size Rear 29
Fork RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, oversized crown for eMTB, Boost110, 15 mm Maxle Stealth, 160 mm travel
Fork Unknown
Gears DERAILLEUR, Shimano, 1 Gears
Tyres BONTRAGER,
Pedals UNBRANDED,
Wheels UNKNOWN, Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Shifters SHIMANO, Shimano Deore M6100, 12-speed,
Kickstand UNKNOWN, Unknown
Front Brake SH, Tektro HD-M745 hydraulic disc // Tektro HD-M745 4-piston hydraulic disc Tektro, 6-bolt, 203 mm Max brake rotor size, Disc brake with hydraulic actuation
Rear Brake SH, Tektro HD-M745 hydraulic disc // Tektro HD-M745 4-piston hydraulic disc Tektro, 6-bolt, 203 mm Max brake rotor size, Disc brake with hydraulic actuation
Rear Derailleur ,
Crankset E_THIRTEEN, E*thirteen E*spec Plus, 160 mm length
Chain SHIMANO, Shimano Deore M6100, 12-speed
Handlebar BONTRAGER, Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Stem BONTRAGER, Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Bartape / Grips BONTRAGER
Seatpost TRANZX
Saddle BONTRAGER, Bontrager Arvada, steel rails, 138 mm width
Front Light UNKNOWN
Rear Light UNKNOWN
Battery Capacity 750
Battery Brand BOSCH
Battery Model BOSCH
Drivetrain Brand Bosch
Sensor Type PEDALFORCE

Please note: Manufacturers can sometimes change the specification of the products from time to time.
