TREK 2024 Rail 9.8 XT Gen 4

Name: TREK 2024 Rail 9.8 XT Gen 4
Brand: TREK
SKU: 5278519
Price: 6474.99 GBP
Availability: OutOfStock

£6,474.99 ~~£9,274.99~~

Selected Colour: LAVA

Select a Size:

Out of Stock ( Call for Availability )

Check store availability

Part Number:

5278519

GTIN/UPC:

601842782293

The Rail 9.8 is a long-travel carbon e-MTB that rips like our beefiest trail rigs and powers you right back up the mountain. You get upgraded everything, including the frame for maximum fun on the gnarliest runs. You also get Bosch's latest tech with the smart system Performance Line CX that has a longer-range 750 Wh battery and cool features that take your ride to the next level like activity tracking, navigation and Bluetooth connectivity. The new System Controller sits almost flush for a sleek look and Mini Remote is discreet and intuitive.

You're looking for a long-travel carbon e-MTB with high-performance parts and a lot of battery power. You crave the responsiveness of carbon, the stability of a longer reach, the plush feel of high-end suspension and want the very latest from Bosch.

An upgraded OCLV Mountain Carbon frame with longer reach and oversized head tube and seat tube for maximum strength. An extra-long-range 750 Wh battery, a super responsive RockShox ZEB Select+ fork and RockShox Super Deluxe Ultimate Thru Shaft shock with a Shimano XT 1x12 drivetrain. You get the latest from Bosch with smart system Performance Line CX, including the new Mini Remote and Bluetooth® System Controller display that's integrated into the top tube.

This bike features across-the-board upgrades that make it a serious ripper - especially the suspension package. It's built for hammering gnarly descents, then flying right back up again thanks to the powerful Bosch motor, 750 Wh battery and parts that can keep up with all that rowdy riding.
- The Carbon Rail Gen 4 has the same enduro-inspired geometry and huge battery as the previous generation, but now it has a pocket in the top tube that makes Gen 4 compatible with Bosch's integrated System Controller and Mini Remote
- The System Controller shows your currently-selected assist level and remaining battery level. It's neatly integrated into the top tube for maximum protection and a sleek look.
- Bosch's smart system gives you all the same power and responsiveness with a new discrete Mini Remote that's streamlined with just the controls you need at your fingertips to toggle through assist levels or change to walk mode
- Intelligent eMTB and eMTB Lite modes adjust the assist automatically based on your input to give you just the right amount of power for your ride
- The new frame is extra stout with a 34.9 mm seat tube to accommodate more robust dropper posts, and an oversized head tube that works with burly e-MTB-optimised forks for less flex and more precise steering

Bosch Performance Line CX motor
The Bosch Performance Line CX sets the standard for eMTB performance with up to 85 Nm of torque and an intelligent eMTB mode with Extended Boost that automatically adjusts the amount of assist based on the terrain.

Removable Integrated Battery
RIB is a one-piece battery and cover with a built-in handle that can easily be removed and re-installed in the frame with no tools and no hassle. It's the most convenient way to remove your battery for transport, security or just easier charging.

Bosch Mini Remote
The compact, ergonomic Mini Remote lets you easily change assist level, activate Walk mode, or turn on optional lights, all without moving your hand off the handlebar. Plus, it's wireless and connects with your System Controller via Bluetooth

Bosch System Controller
The System Controller gives you a quick overview of your assist mode and battery level without distracting you from the ride. It's integrated into the top tube so it's out of the way but still easy to see with LED indicators. It also connects to the eBike Flow app via Bluetooth for accessing ride stats and performing system updates.

Active Braking Pivot
Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.

Bosch eBike Flow app
The new eBike Flow app turns your ride into a personalised experience. Use it to customise your motor's assist behaviour, track your ride stats and integrate your data with apps like Strava and Apple Health. There's even handy features like navigation and service reminders.

Specification

Frame	Size XL, UNI, Carbon, OCLV Mountain Carbon main frame, 1.8'' lower head tube, Bosch System Controller-compatible, Removable Integrated Battery (RIB), Knock Block 2.0, guided internal routing, 34.9 mm seat tube, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru-axle, 150 mm travel
Wheel Size	Front 29
Wheel Size	Rear 29
Fork	RockShox ZEB Select+, DebonAir spring, Charger 3 RC2 damper, 1.8"" oversized tapered steerer, eMTB optimised crown, 44 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel
Fork	Unknown
Gears	DERAILLEUR, Shimano, 1 Gears
Tyres	BONTRAGER,
Pedals	UNBRANDED,
Wheels	BONTRAGER, Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"" Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12Â mm thru axle, 29""
Shifters	SHIMANO, Shimano XT M8100, 12-speed,
Kickstand	UNKNOWN, Unknown
Front Brake	SH, Shimano XT M8120 4-piston hydraulic disc // Shimano XT M8120 4-piston hydraulic disc Shimano RT76, 6-bolt, 203 mm Max brake rotor size, Disc brake with hydraulic actuation
Rear Brake	SH, Shimano XT M8120 4-piston hydraulic disc // Shimano XT M8120 4-piston hydraulic disc Shimano RT76, 6-bolt, 203 mm Max brake rotor size, Disc brake with hydraulic actuation
Rear Derailleur	,
Crankset	E_THIRTEEN, Ethirteen Espec Plus, 165 mm length
Chain	SHIMANO, Shimano XT M8100, 12-speed
Handlebar	BONTRAGER, Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Stem	BONTRAGER, Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 45 mm length
Bartape / Grips	BONTRAGER
Seatpost	BONTRAGER
Saddle	BONTRAGER, Bontrager Arvada, austenite rails, 138 mm width
Front Light	UNKNOWN
Rear Light	UNKNOWN
Battery Capacity	750
Battery Brand	BOSCH
Battery Model	BOSCH
Drivetrain Brand	Bosch
Sensor Type	PEDALFORCE

Please note: Manufacturers can sometimes change the specification of the products from time to time.
